Projects

Project Name:  Solar PV Plants for L&T Metro Miyapur Depot, JNTU and Kukatpally Stations

Organization Name: L&T Metro

Projects Capacity: 500 kWp

Project Location: Hyderabad

Type of Plant: On-grid | Curved and Flat Metal Roofs

Technical details

PV Modules: Poly 335Wp modules

Inverter: 50 Kw Inverters

Overview: The project has major challenges around safety as 1) metal roof is curved and at a height of more than 25 meter from ground 2) Installation is possible during night time (1 am - 4 pm) when train movements are stopped 3) Months of installation were June to September with rains. Soorpa Energy's team not only handled the challenge but also met the stringent quality and safety requirements of L&T.

It has added immense experience and confidence to the Soorpa Energy. We would not be exaggerating if we say we definitely sit in the top of the table on technical and safety understandings of solar plants.

Project Name:  Solar PV Plant at 14,500ft for Boarder Police

Organization Name: Boarder Police

Project Capacity: 122 kWp

Project Location: Near Leh

Type of Plant: Off-grid | Combination of Metal Roof and Ground mount

Technical details

PV Modules: Poly 320Wp modules

Inverter: 1 No of 30kW and 2 No's of 50kW inverters

Battery Bank: 630kWh for 2 days back up

Overview: Soorpa Energy was trusted to develop a 122 kWp off-grid Solar PV plant for boarder police near China at an altitude of 14,500 feet from the sea level. Temperature at the site goes down to -40 degrees in winter. Terrain is rugged and air pressure is low at this altitude. They pose design challenges as solar plant components are not manufactured for low air pressure, extreme temperatures and snow loads. We successfully tackled the design, transportation and installation challenges faced. Trust to handle the technically challenging project is a testimony to our technical knowledge and design capability.

Project Name:   25 KWP On-Grid Solar Plant for IOCL Petrol Bunk

Company Name: IOCL Petrol Bunk

Project Capacity: 25 kWp

Project Location: Uttarkashi, Uttarakhand

Type of Plant: On-grid | Metal Roof

Technical details

PV Modules: Poly 320Wp

Inverter: 1 No of 10kW and 1 No of 15kW inverter

Annual Generation: 35,000 KWh

Emissions curbed: 712 Tonnes over project lifetime of 25 years

Overview: IndianOil Corporation Ltd is India's largest commercial enterprise. The IndianOil Group of companies owns and operates 10 of India's 20 refineries. Soorpa Energy developed a rooftop solar plant of 25 kWp capacity for one of its petrol bunk facility in Uttarkashi, Uttarakhand. The plant will annually produce green electricity of 35,000 KWh. It also results in curbing 712 tonnes of Co2 emissions which is equivalent to planting 18,471 trees in India.
